3 Series E93 330d (M57T2) CONVER
Installation:
Feed driver (1) into slot (3) in lever (2) of coupling gear.
Align lever (2) on coupling gear so that slot (3) is correctly
positioned with respect to driver (1).
Installation:
Pin on coupling gear must reach into hole in seat.
Installation:
Make sure groove and pin are correctly positioned.
Clip flexible shaft (1) into place with coupling gear (2).
Ensure complete engagement by pulling gently on flex shaft.
Flexible shaft must not clip out here!
Unclip flexible shaft (3) from cable tie (2).
Unclip cable tie (1) from backrest.
RA Removing and installing or replacing front seat belt
