3 Series E93 330i (N53) CONVER
Seal fuel line connections of high-pressure pump (1) with
matching plugs from special tool kit 32 1 270 .
Release screws with special tool 11 8 610 .
Detach high-pressure pump (1) and remove.
Engine oil can escape when pump is detached; have a cleaning
cloth ready.
Installing high-pressure pump:
Installation of high-pressure pump is described separately from
removal.
Replace sealing ring (1).
Clean contact faces.
RA Removing and installing or replacing high-pressure fuel pump (N54, N53)
