3 Series E93 330i (N53) CONVER
Important!
Connect pressure line (1) without tension only.
To ensure distortion-free installation of the pressure line and
to avoid damaging the thread, it must be possible for both
nuts to be screwed on easily by hand!
If the nuts cannot be easily screwed on by hand, the injector
must be turned into the installation position!
Note:
Description of "Turning injector into installation position" in the
following two work steps.
Only if injector has to be turned into installation position:
•
Release screw a few turns until holding-down element (1) is
slackened.
•
Turn injector (2) in direction of arrow until nuts on pressure
line can be easily screwed on by hand.
•
To do so, engage wrench on hexagon head of injector if
necessary.
•
Tighten nuts on pressure line hand-tight.
Important!
Do not under any circumstances pull injector out of bore!
If the injector is pulled out of the bore hole, the PTFE sealing
ring must be replaced! Replacing PTFE sealing ring, refer to
13 53 310 .
Tighten down screw for holding-down element (1).
Tightening torque 13 53 5AZ
.
RA Removing and installing or replacing a high-pressure line (N54, N53)
