3 Series E93 330i (N53) CONVER
Open weld joints in areas (1).
Open weld joints in area (1).
Cut severance cut along line (2).
Measurement a = 20 mm from radius
Installation:
For reasons of accessibility, the repair joining sequence differs
from the standard joining sequence.
Adjust new part in conjunction with side panel to fit.
Attach new component from outside and weld.
View from below:
Open weld joints in area (1).
Preparation of new part:
Scribe new part along line (1) with 20 mm overlap to vehicle and
cut.
RA Replacing rear left outer wheel arch section (rear left side panel removed)
