5 Series E39 520d (M47) TOUR
Remove center console.
Remove trim for instrument panel (lower section).
Remove lower section of steering column casing with footwell trim.
Remove left footwell air duct.
Release screws and pull out left footwell air outlet in direction of
arrow.
Unfasten screws and remove pipes.
Installation:
Replace sealing rings.
Unfasten screw and remove bracket.
RA Replacing heater core (automatic A/C)
