5 Series E39 520d (M47) TOUR
Unfasten bolt from automatic safety belt tensioner of center safety
belt.
Installation:
Tightening torque,
refer to Technical Data 72 11 1AZ
Installation:
Observe coding!
Lug (1) of back-rest must lie in recess (2) of center automatic
safety belt tensioner for fixing.
Remove Bowden cable from brackets in back-rest and take out
automatic seat belt tensioner.
Installation:
Bowden cable must lie in brackets and guide in lock of back-
rest lock.
RA Removing and installing / replacing rear center safety belt
BMW AG - TIS
26.01.2013 06:04
Issue status (12/2007) Valid only until next DVD is issued
Copyright
Page - 2 -
