5 Series E39 520i (M52) TOUR
11 61 050
Removing and installing intake air manifold
(M52)
Note instructions on removing and disconnecting battery,
refer to General Information MG 12
Disconnect negative battery lead.
Removing intake air housing with mass air flow sensor,
refer to 13 71 000
Only E39
Remove cover on windshield and left air duct. This operation is
described in section on removing complete wiper console,
refer to 61 61 270
Lift off cover (1).
Unclip positive battery lead by pulling downwards.
RA Removing and installing intake air manifold (M52)
