5 Series E39 520i (M52) TOUR
Unfasten nuts (1 and 2) from starter motor.
Tightening Torque,
refer to Technical Data 12 41 4AZ.
Installation:
Note line routing.
When installing nut (1), make sure that lines (2 and 3) are laid
without kinks or abrasions.
Tightening Torque,
refer to Technical Data 12 41 4AZ.
Disconnect plug connection (1) on knock sensors.
Disconnect plug connection (2) of pulse generator on vibration
damper.
Disconnect plug connection (3) of cylinder detection sensor.
Disconnect plug connection on reversing light switch. Note wire
routing!
RA Wiring harness - replacing engine section (M52)
