Troubleshooting on pull-out luggage compartment loading floor (touring)
Troubleshooting:
Fault
Cause
Remedy
Stiff longitudinal movement
a)
Side roller blocks set too closely
b)
Rails on car side set too closely
c)
Excessive friction when floor is
retracted and locked
a)
Adjust side roller blocks,
refer to 51 47 111.
b)
Adjust rails on car side,
refer to 51 47 111.
c)
Coat rails with Universal
protecting spray (sourcing
reference: BMW Parts Service)
(do not use grease)
Luggage compartment loading floor
does not lock:
a)
Rails on car side set too closely
b)
Roller blocks twisted
c)
When extended, handle does
not spring powerfully back to
retracted position
a)
Adjust rails on car side,
refer to 51 47 111.
b)
Loosen blocks and retighten
when snapped into place
c)
Replace luggage compartment
loading floor,
refer to 51 47 112.
Interference noise:
Interference noise
Cause
Remedy
Linkage rattles
a)
Loading floor not locked on
both sides (handle reveals
clearance when closed)
a)
See Luggage compartment
loading floor does not lock
Noises in area of middle support
a)
Foundation does not engage
because support is bent. Rear
edge of roller should be flush
with rear edge or protrude a
little towards rear.
b)
Plastic insert (foundation)
broken on underside of handle
a)
Release bracket with trunk lid
lock and retighten while a 2nd
person pulls the support back
b)
Replace luggage compartment
loading floor,
refer to 51 47 112.
Noises in area of rear roller blocks
a)
No lateral clearance
b)
Lateral clearance
a)
Adjust lateral clearance
b)
Adjust middle support approx. 2
mm lower
Squeaking noises from rollers
a)
Rollers not lubricated
