5 Series E39 530d (M57) SAL
Detach plug (1) from pressure sensor (2).
Release union nut (1) on pressure accumulator with special tool
13 5 020 .
Release union nut (1) on H.P. pump with special tool 13 5 020 .
Remove pressure line from pressure accumulator.
Tightening torque.
Release screws (3).
Remove pressure accumulator (4).
Installation:
Observe installation position of rubber mount (2).
RA Removing and installing/replacing pressure accumulator of injection system (M57)
