Replacing Shaft Seal For Torque Converter - BMW 5 Series E60 528i (N52K) AUT
Attach special tool 24 2 353 to drive shaft (1).
Screw in special tool 24 2 351 until it is firmly connected with
shaft seal.
Screw in special tool 24 2 352 to remove shaft seal.
Oil sealing lip on shaft seal.
Drive in shaft seal (1) with special tool 24 2 400 as far as it will
go.
RA Replacing shaft seal for torque converter (GA6HP19Z)
