5 Series E60 530Li (N52K) SAL
Unlock catches (1) in direction of arrow.
Pull airbag control unit with gateway module (2) out of equipment
carrier (3) slightly.
Unlock plug connections (4) and disconnect.
Remove airbag control unit with gateway module (2).
Replacement:
Carry out programming/coding.
RA Removing and installing (replacing) airbag control unit with gateway module
BMW AG - TIS
22.02.2013 08:42
Issue status (12/2007) Valid only until next DVD is issued
