5 Series E60 535d (M57TU) SAL
Open drain plug (1) on radiator.
Open drain plug (1) on engine block.
Installation:
Replace seal.
Tightening torque: 11 11 5AZ
.
Open vent screws (1) and (2).
Assemble engine.
Note:
Adhere to the following work sequence when adding coolant.
1.
Slowly fill expansion tank with coolant.
2.
Switch on ignition.
3.
Set temperature controller to maximum heating.
4.
Close vent screws on coolant pipe once bubble-free coolant
has emerged.
Use only recommended coolant, refer to BMW Service Operating
Fluids MG17.
Vent cooling system.
RA Draining and adding coolant (M57TU)
