5 Series E60 535d (M57TU) SAL
Version with Dynamic Drive:
Release nuts (1) and (2).
Remove retaining fixture (3).
Installation:
Make sure retaining fixture (3) is correctly seated.
All:
Unfasten plug connection (1) and disconnect.
Release screws (2).
Detach refrigerant lines (3) in direction of arrow.
Installation:
Tightening torque 64 52 1AZ.
Replace all sealing rings and moisten with refrigerant oil.
All:
Note:
Secure A/C compressor (2) against falling out.
Release screws (1).
Feed out A/C compressor (2) in direction of arrow.
After installation:
•
Evacuate and fill A/C system
RA Replacing A/C system compressor (M57, M54)
