5 Series E60 535d (M57TU) SAL
11 11 Engine Block, Cylinder Crankcase M57TU D30
Bore
∅
stage 0 a)
mm
82.007
±
0.007
Bore
∅
stage 00 a)
mm
Bore
∅
stage 1 a)
mm
82.257
±
0.007
Permitted out-of-round of cylinder bore a)
mm
0.005
Permitted conicity of cylinder bore a)
mm
0.01
Permissible total wear tolerance between piston and
cylinder (engine operated)
mm
0.15
a) new status or recondition
