5 Series E60 545i (N62) SAL
35 11 000
Removing and installing complete bearing
block for foot pedal
Necessary preliminary tasks:
•
Remove pedal trim
•
Vehicles with electric steering column:
-
Remove electric steering column drive
•
Vehicles with manual transmission:
-
Remove clutch pedal
-
Remove clutch master cylinder
Important!
After completion of work, carry out function check.
Unfasten plug connection (1).
Remove locking clip (2) and disengage and pull out locking pin.
Release nuts (3) and remove bearing block.
Installation:
Replace self-locking nuts.
Tightening torque 35 11 1AZ.
RA Removing and installing complete bearing block for foot pedal
BMW AG - TIS
22.02.2013 18:22
Issue status (12/2007) Valid only until next DVD is issued
Copyright
Page - 1 -
