5 Series E60 M5 (S85) SAL
52 24 ...
Checks on rear seat (basic)
The rear seats must be checked for damage following an accident. This measure is applicable above all in the event
of structural damage (engine carriers, luggage compartment floor side members) but also if large pieces of luggage
were stowed in the luggage compartment. The most important checks are set out below.
1
Rear seat
3
Center armrest
2
Backrest
4
Head restraints
1. Rear seat frame:
Check complete frame for damage (cracking, breakage, etc.),
paying particular attention to the marked areas.
RA Checks on rear seat (basic)
BMW AG - TIS
23.02.2013 03:35
Issue status (12/2007) Valid only until next DVD is issued
