5 Series E61 535d (M57T2) TOUR
51 41 001
Replacing front left or right door trim panel
(up to 03/2007)
Necessary preliminary tasks:
•
Remove front door trim panel
•
Remove toggle switch
•
Remove airbag module in front door
•
Remove inside door handle
•
Remove inside door opener
•
Remove speaker
•
Replace armrest
•
Replace door pocket
Version with interior light package:
•
Remove trim for door handle/door compartment light
Version with interior light package:
Cut out opening (1) at moulding (2) with a scalpel.
Important!
Ensure a clean cut so that the door trim panel cover (3) is not
damaged.
RA Replacing front left or right door trim panel (up to 03/2007)
