5 Series E61 535d (M57T2) TOUR
61 31 175
Removing and installing/replacing switch for
slide/tilt sunroof
Necessary preliminary tasks:
•
Remove front roofliner trim
Press catches (1) and unclip switch for sunroof (2) in direction of
arrow from front roofliner trim (3).
Installation:
•
Initialize slide/tilt sunroof.
RA Removing and installing/replacing switch for slide/tilt sunroof
BMW AG - TIS
19.02.2013 15:24
Issue status (12/2007) Valid only until next DVD is issued
