5 Series E61 535d (M57T2) TOUR
Release screws (1).
Pull back fixture for steering column switch (2) in direction of
arrow.
Disconnect plug connections behind and remove fixture for
steering column stalk (2).
Replacement:
•
Remove turn indicator/headlight dipping switch
•
Remove windshield wiper switch
•
If necessary, remove cruise control switch
•
Remove volute spring cassette
Replacement:
•
Carry out programming/coding
•
Vehicles without active front steering:
•
Carry out steering angle sensor adjustment
•
Vehicles with active front steering:
•
Carry out active front steering start-up/adjustment.
RA Removing and installing/replacing fixture for steering column stalk (up to 09/20
