5 Series E61 535d (M57T2) TOUR
61 36 560
Removing and installing/replacing headlight
washer relay
Necessary preliminary tasks:
•
Open glovebox.
Unclip pin (1) from shock absorber (2).
Open rotary clips (1) and remove cover (2) in direction of arrow.
Detach relay (1).
RA Removing and installing/replacing headlight washer relay
BMW AG - TIS
19.02.2013 16:19
Issue status (12/2007) Valid only until next DVD is issued
