5 Series E61 535d (M57T2) TOUR
65 24 020
Removing and installing or replacing blocking
circuit
Special tools required:
•
00 9 341
Necessary preliminary tasks:
•
Remove trim for rear left and right roof pillar (C-pillar)
•
Remove trim for rear left and right roof pillar (D-pillar)
•
Remove rear grab handles
Lever out right speaker cover (1) at points (2) with special tool
00 9 341 .
Feed speaker cover (1) in direction of arrow out of roofliner (3)
and remove.
Installation:
Lugs (1) and locks (2) of speaker cover (3) must not be
damaged.
Make sure speaker cover (3) is completely engaged in roofliner.
RA Removing and installing or replacing blocking circuit
BMW AG - TIS
19.02.2013 18:25
Issue status (12/2007) Valid only until next DVD is issued
