5 Series E61 535d (M57T2) TOUR
37 12 Control and Suspension Systems, rear
Type
Thread
Tightening specification
Measure
1AZ Pressure line connections
E38 / E39
M10
14 Nm
2AZ Pressure line connections
E38 / E39
M12
20 Nm
3AZ Screw connection for air line
E39 / E53 /
E61 / E65 /
E66
Dia. =
4 mm
2 Nm
E53
Dia. =
6 mm
4 Nm
4AZ Lever on stabilizer:
E38
tighten one nut to 5 Nm,
then second nut to 9 Nm,
then first nut to 9 Nm.
9 Nm
5AZ Air suspension on wheel carrier
E39
20 Nm
6AZ Air spring strut to wheel carrier
E65 / E66
M14
Replace screw
165 Nm
7AZ Pressure sensor to pressure
accumulator
E53
9 Nm
AZD Control and Suspension Systems, rear
