6 Series 630i (N53) Coupe
51 71 447
Removing and installing or replacing panel
for cover on left or right side member
Necessary preliminary tasks:
•
Remove entrance cover strip
•
Detach wheel arch cover from front/rear side member cover
Release expansion rivets (1).
Release screws (1).
Unclip panel (1) at front.
Unclip rear panel (1) from holder (2).
Open door and remove panel (1) in direction of arrow.
RA Removing and installing or replacing panel for cover on left or right side membe
