6 Series 630i (N53) Coupe
Remove protective cap (2) from condenser for A/C system (3)
with aid of an inserted screw (1).
Installation:
Replace sealing rings (1) of sealing cap (2) and coat with
suitable refrigerant oil.
Remove desiccant insert for A/C system (1) in direction of arrow
from condenser for A/C system (2).
After installation:
•
Add final details to vehicle
•
Evacuate and fill A/C system
RA Replacing desiccant insert for A/C system (condenser removed)
