6 Series 650i (N62TU) Coupe
Unclip door wiring harness (3) at points (1).
Release expansion rivets (2).
Installation:
Make sure door wiring harness is correctly laid.
Release screw (1), fold door wiring harness plug on A-pillar (2)
downwards slightly and remove.
Unlock plug connection behind and disconnect.
Pull rubber grommet (3) out of front door.
Feed out door wiring harness towards front to A-pillar and remove.
RA Replacing wiring harness in left or right front door
