7 Series E38 740iL (M62) SAL
Unfasten guide tube for dipstick on oil pan.
Installation:
Check O-ring, replace if necessary.
Insert O-ring and washer in oil pan bore.
Unfasten return line from oil pan.
Installation:
Replace sealing ring.
For Tightening torque,
refer to Technical Data 11 42 5AZ
Unfasten steering spindle from steering gear.
This operation is described in section on removing and installing
the steering gear,
refer to 32 13 060
Unfasten bracket for hydraulic line from front axle support.
Brace front axle support with special tool 00 2 030 in
conjunction with special tool 31 2 220.
Unfasten front axle support from engine support and lower
approx. 60 mm,
refer to 31 11 001
RA Removing and installing/replacing upper section of oil pan (M62)
