7 Series E38 740iL (M62) SAL
Installation:
Remove outer and inner gasket from cylinder head cover.
Insert special tool 11 6 432 from special tool kit 11 6 430
in groove of cover and fit cylinder head cover.
Installation:
Install cover nuts (1) and tighten down uniformly in 1/2 turn
steps.
Tightening Torque,
refer to Technical Data 11 12 11AZ.
Note:
The timing case cover is pressed down onto level of cylinder
head by cylinder head cover.
Installation:
Tighten screws (1) on timing case cover in two passes.
Remove cylinder head cover and remove special tool 11 6 432.
RA Removing and installing timing case cover, top left (M62 VANOS from 9/98)
