7 Series E38 740iL (M62) SAL
Caution!
Left-hand threads.
Slacken screw connection (1) of exhaust camshaft on cylinder
bank 5 to 8 by approx. a half turn.
Caution!
Left-hand threads.
When releasing camshaft screw connection: grip camshaft at
hexagon head.
Slacken screw connection (1) of exhaust camshaft on cylinder
bank 1 to 4 by approx. a half turn.
Caution!
Left-hand threads.
When releasing camshaft screw connection: grip camshaft at
hexagon head.
Slacken screw connection (2) of inlet camshaft on cylinder
bank 5 to 8 by approx. a half turn.
Caution!
Left-hand threads.
When releasing camshaft screw connection: grip camshaft at
hexagon head.
Slacken screw connection (2) of inlet camshaft on cylinder
bank 1 to 4 by approx. a half turn.
RA Removing and installing/replacing left camshaft adjustment unit (M62 VANOS from
BMW AG - TIS
17.02.2013 15:54
Issue status (12/2007) Valid only until next DVD is issued
