7 Series E38 740iL (M62) SAL
Compact final drive:
Detach drive flange with special tools 31 2 101 , 31 2 102 ,
31 2 103 .
Pull out shaft seal with special tool 00 5 010 .
Drive in new shaft seal as far as it will go:
-
Special tools 00 5 500 and 33 3 440 for transmission type
"G" (side cover with 8 screws) and compact. 188
-
Special tools 00 5 500 and 33 3 470 for transmission type
"M" (side cover with 6 screws) and compact 220/215
Coat sealing lips of shaft seal and sealing face of drive flange with
differential oil.
Clean drive flange and attach.
Press on drive flange with special tools 23 1 300 , 23 1 302
and 33 1 341 until nut can be screwed on.
RA Replacing shaft seal for input flange on final drive
