Adjust reinforcement plate on transmission tunnel to fit and weld
down.

Grind welding spots until smooth.

RA  Replacing front section of left engine support

BMW AG - TIS

18.02.2013  02:00

Issue status (12/2007) Valid only until next DVD is issued

Copyright

Page  - 8 -
