7 Series E38 740iL (M62) SAL
Insert central key in and twist to left: this unlocks upper section of
trunk lid lock.
1 = upper section of trunk lid lock locked
2 = upper section of trunk lid lock unlocked
Caution!
Before closing the trunk lid, always check whether the upper
section of the trunk lid lock has been unlocked. There is
otherwise a risk of damaging the upper or lower section of the
trunk lid lock.
Caution!
Before locking, ensure that trunk lid is not able to damage the
body or the rear window.
If necessary, first roughly cut the trunk lid to size.
Carefully close trunk lid and adjust to fit side panels.
Open trunk lid, taking care not to alter the adjustment.
Tighten left and right screws (1) and (2).
Tighten down lower section of trunk lid lock.
Close trunk lid and check adjustment, repeating if necessary.
Open trunk lid.
If the trunk lid was not fitted, carry out following preliminary work
before adjusting the Soft Close Automatic:
RA Adjusting trunk lid to fit
