7 Series E38 740iL (M62) SAL
Unfasten all clips and remove heater core cover.
Unfasten screws (1) and pull out heater core (2).
Installation note:
Replace O-rings.
When replacing the heater core, pull out retaining clips (1) and
reroute wires.
Installation note:
Replace O-rings. When installing the pipes, ensure proper
seating of the O-rings.
RA Replacing heater core (air conditioner control)
