7 Series E65 740i (N62TU) SAL
Hold torsion spring (1) with special tool
11 9 480 .
Install intermediate lever (2) from above.
Insert end of torsion spring (1) into guide on intermediate
lever (2).
Install eccentric shaft sensor (2).
Insert screws and tighten down eccentric shaft sensor (2).
Remove special tool 11 9 474 .
Remove special tool 11 9 472 and special tool 11 9 475 .
RA Removing and installing/replacing right inlet camshaft (N62 from 9/03 and N62TU)
