7 Series E66 745Li (N62) SAL
62 11 280
Removing and installing (replacing)
instrument cluster
Necessary preliminary tasks:
•
Remove wood trim on instrument panel on left.
Release screws (1).
Fold instrument cluster (2) towards rear and remove in direction
of arrow.
Disconnect plug connection behind.
Installation:
Retaining lugs (1) of instrument cluster (2) must be exactly
seated in mountings of instrument panel.
Replacement:
Carry out coding/programming.
Observe following IDC specifications:
•
Programming
•
Coding
•
Car & Key Memory
•
CD "CIP"
RA Removing and installing (replacing) instrument cluster
