X Series E53 X5 3.0d (M57) OFFRD
Slacken screw (1) on hydraulic chain tensioner (for oil pressure
reduction).
Mount special tool 11 6 322 on cylinder head.
Position special tool 11 6 321 on inlet camshaft and secure
with special tool 11 6 322 (1).
Carefully and slowly rotate exhaust camshaft at Torx bolt in
direction of engine rotation until hydraulic chain tensioner is
compressed.
RA Replacing camshafts (M57)
