X Series E70 X5 3.0Sd (M57T2) OFFRD
64 12 670
Replacing front electric auxiliary heater
Necessary preliminary tasks:
•
Remove carrier for instrument panel
Note:
For purposes of clarity, the following graphics show the heater/air
conditioner removed.
Disconnect plug connection (1).
Release screws (1).
Lay servomotor (2) to one side.
RA Replacing front electric auxiliary heater
