X Series E70 X5 3.0Si (N52K) OFFRD
Note:
Once the laser has been aligned to the camera lens, it is
necessary to calibrate the reversing camera via the DIS Tester.
Also switch on reversing camera by means of PDC button.
Calibration can only be carried out with the BMW diagnosis
system.
Service functions:
->Complete vehicle
->Body
->Camera systems
Note:
For information on ordering the reversing camera adjustment unit,
see Service Information 205 07 349
.
Observe information on use of CORGHI KDS quick-action clamp !
Secure KDS quick-action clamp on rear wheels on both sides.
Insert ball pivot (1) in guide (2) up to stop and secure with
screw (3).
RA Calibrating reversing camera
