X Series E83 X3 2.0d (M47T2) OFFRD
25 11 000
Removing and installing shift lever
Special tools required:
•
25 1 120
Necessary preliminary tasks:
-
Remove complete exhaust system.
-
Remove heat shield.
-
Remove transmission cross-member.
Release screws.
Tightening torque 26 11 6AZ
.
Note:
Lower transmission.
Important!
Risk of damage:
Engine must not rest against bulkhead.
RA Removing and installing shift lever
