X Series E83 X3 2.0d (N47) OFFRD
Release lock (1) in direction of arrow.
Release pressure pipe (2) in direction of arrow.
Important!
In the event of a leak at the pressure pipe, there is a risk of
damage to the exhaust-gas turbocharger.
Check sealing lip (1) for damage.
Installation:
If sealing lip (1) is damaged, the pressure pipe must be replaced.
Important!
In the event of a leak at the pressure pipe, there is a risk of
damage to the exhaust-gas turbocharger.
Check sealing ring for damage.
Installation:
If the sealing ring is damaged, the pressure pipe must be
replaced.
Assemble engine.
Check intake manifold for leaks.
RA Removing and installing/replacing pressure pipe on throttle valve assembly (N47,
