X Series E83 X3 2.5Si (N52K) OFFRD
Install bearing shell (1) with tip facing down (see arrow) in
cylinder head.
Install bearing shell (2) with tip facing up in bearing cap.
Note:
All bearing caps (1 and 2) of eccentric shaft are marked with
numbers from 1 to 6 (1 for 1st cylinder to 6 for 6th cylinder).
Bearing cap 6 (1) is provided with a stop.
Insert eccentric shaft.
Adjust eccentric shaft on dihedron to minimum stroke.
Fit all bearing caps (1 and 2).
Insert all screws.
Tightening torque 11 12 7AZ
.
Assemble engine.
RA Removing and installing/replacing eccentric shaft (N52K)
