X Series E83 X3 2.5Si (N52K) OFFRD
Installation:
Observe the following procedure when installing the fuel level
sensor.
1.
Carefully push fuel level sensor (1) in direction of arrow onto
sensor holder (2).
2.
Fuel level sensor must snap audibly into place!
3.
Carefully feed cable into cable guides (3).
Do not kink cable.
Make sure fuel level sensor is correctly positioned in both
guides (see arrows).
Installation:
Lay cable (1) through upper loop of tank support (2).
Illustration shows cutaway model:
Installation:
Cable (1) must be laid under line (2) and engaged in cable
holder (3).
RA Removing and installing/replacing fuel gauge sensor (petrol/gasoline, right, N52
