X Series E83 X3 2.5Si (N52K) OFFRD
E83:
If fitted, release drain plug (1) on coolant radiator.
On coolant radiators which do not have a drain plug, remove
coolant hose.
Open vent screw (1).
Use only recommended coolant, refer to BMW Service Operating
Fluids MG17.
Note:
Adhere to the following work sequence when adding coolant.
-
Switch ignition on
-
Seat heating to maximum temperature and fan to low speed
(heater valves are opened and auxiliary water pump starts
up).
-
Slowly fill expansion tank with coolant.
-
Close vent screw after bubble-free coolant emerges or after
filling up to max. cold fill level.
Vent cooling system.
RA Draining and adding coolant (N52K)
