X Series E83 X3 2.5Si (N52K) OFFRD
Detach knob with a firm tug.
Note:
Do not turn knob when detaching as this will shear off the turning
lock in the knob.
Installation:
Fit knob on shift lever, align and press on until it snaps noticeably
into place.
Note:
Illustration shows E46.
Press installation frame of rubber gaiter (1) together a little and
remove rubber gaiter (1) from centre console.
Installation:
Feed gaiter (1) downwards and fit on shift lever (2).
Pull rubber gaiter (1) over selector lever and insert in centre
console.
Installation:
Push rubber gaiter (1) down until groove (2) is fully exposed.
RA Removing and installing shift lever
