X Series E83 X3 2.5Si (N52K) OFFRD
27 10 700
Removing and installing / replacing control
unit for transfer case
Important!
Read and comply with notes on protection against
electrostatic damage (ESD protection).
After installation:
•
After replacement, the "Repair" service function must be
carried out with GT1.
•
Replacement only: Carry out programming/coding
In vehicles before 03/05 the old diagnosis algorithm and in
vehicles after 03/05 the new diagnosis algorithm must always
be activated by way of coding!
Necessary preliminary tasks:
•
Remove front panel for luggage compartment floor.
Unscrew nuts (1).
Unfasten plug connection and disconnect.
Remove control unit (2).
RA Removing and installing / replacing control unit for transfer case
