X Series E83 X3 2.5Si (N52K) OFFRD
Support swivel bearing (1) with workshop jack and a suitable
mounting.
Release nut and remove bolt (2) towards front.
Expand swivel bearing (1) with special tool 31 2 230 .
Lower workshop jack.
Remove swivel bearing (1).
Installation:
Replace self-locking nut.
Tightening torque 31 31 3AZ
.
Installation:
Keep press fit of swivel gearing and spring strut in lower area
clean and free from oil and grease.
Spread swivel bearing (1) with special tool 31 2 230 , align by
means of gap to positioning pins (2) on back of spring strut and
raise as far as it will go.
Replacement:
Modify dust sleeve (1).
Modify brake guard plate (2).
Installation:
Install new wheel bearing.
Draw in drive flange.
After installation:
•
Replacement only: Perform chassis alignment check
