X Series E83 X3 2.5Si (N52K) OFFRD
Increase pressure with Torx screwdriver T30 (1) on spring
leg (2) until airbag unit is unlocked.
Repeat procedure on other side.
Installation:
Make sure electrical leads are correctly positioned.
Snap airbag unit with uniform pressing force plane-parallel in
direction of steering column shaft into steering wheel.
Warning!
Danger of injury!
Airbag unit may only be set down with the airbag itself facing
upwards.
Tilt airbag unit (1) slightly to one side.
Slide screwdriver (2) from front into both plug connections (3)
until cover lifts off.
Disconnect plug connections (3).
Remove airbag unit (1).
Installation:
Connect plugs to connections of same colour on airbag unit.
RA Removing and installing / replacing airbag unit (sport steering wheel)
