X Series E83 X3 2.5Si (N52K) OFFRD
33 31 011
Replacing rear axle carrier
Necessary preliminary tasks:
•
Remove rear differential
•
Remove complete rear axle carrier
Disengage handbrake Bowden cables from expander lock and
feed out of rear axle carrier.
Remove stabilizer bar.
Remove lower control arm from rear axle carrier .
Remove upper control arm on both sides from rear axle carrier
and remove with trailing arm and output shaft.
If necessary, remove height setting sensor and bracket.
If necessary, remove vibration damper.
After installation:
•
Adjusting handbrake
•
Perform chassis alignment check
RA Replacing rear axle carrier
