X Series E83 X3 2.5Si (N52K) OFFRD
51 11 140
Removing and installing/replacing bumper
trim upper section (up to 09/2006)
Necessary preliminary tasks:
•
Remove front bumper trim
•
Remove both fog lamps
•
Remove radiator grille for bumper trim
•
Remove centre insert for bumper trim
Note:
The operation is described on the left side; proceed in the same
way for the right side.
Release screws (1).
Unhook catches (2) on bumper trim (3).
Release catches (1) and remove upper section of bumper
trim (2).
Installation:
If necessary, replace faulty metal nuts (1) on upper section of
bumper trim (2).
Replacement:
Remove centre radiator grille.
Version with headlight washer system:
If necessary, remove spray nozzles (3).
RA Removing and installing/replacing bumper trim upper section (up to 09/2006)
