X Series E83 X3 2.5Si (N52K) OFFRD
51 24 165
Removing and installing/replacing side left or
right buffer stops on rear lid
Necessary preliminary tasks:
•
Remove panel for roof pillar at rear (D-pillar)
Note:
The operation is described on the left side; proceed in the same
way for the right side.
Adjustment, refer to:
Last 3 work steps.
Release lock nut (1) on buffer stop.
Note:
Grip guide in water gutter.
Release nut (2) on buffer stop guide.
Installation:
(1)
Tightening torque 41 62 4AZ
.
(2)
Tightening torque 41 62 3AZ
.
Remove buffer stops outwards.
Installation:
Following parts of buffer stops must not be missing or damaged:
1
Adjustable buffer stop
2
O-ring
3
Guide
4
Guide O-ring
5
Guide nut
6
Lock nut
Important!
RA Removing and installing/replacing side left or right buffer stops on rear lid
BMW AG - TIS
11.02.2013 17:36
Issue status (12/2007) Valid only until next DVD is issued
